AutoCAD Civil 3D 2017 Service Pack 1.1 recently released Service Pack 1.1. If you troubles with it, below are the issues fixed in the new service pack…
The API has been extended to enable match line and view frames.
The .NET API has been extended to enable write access for setting cant on a railway alignment.
An API has been added to create a siteless feature line :
static NAMESPACE_ACDB::ObjectId Create(System::String^ featurelineName, NAMESPACE_ACDB::ObjectId idCreatedFrom);
An API has been added to move a feature line to none site:
static void MoveToNoneSite(NAMESPACE_ACDB::ObjectId featureLineId);
An API has been updated to allow a feature line to be moved to none site:
static void MoveToSite(NAMESPACE_ACDB::ObjectId featureLineId, NAMESPACE_ACDB::ObjectId destinationSiteId);
Alignments and Profiles
In AutoCAD Civil 3D 2017 Service Pack 1.1, when using of object snaps has been enabled for profile view lines.
An issue where a drawing created in AutoCAD Civil 3D 2016 would display station numbers with extra characters when opened in AutoCAD Civil 3D 2017 has been resolved.
An issue that caused the superelevation diagrams to display a design check warning with a blank tooltip has been resolved.
An issue that caused the Superelevation Tabular Editor to display a rate of change warning with a blank tooltip has been resolved.
An error is no longer reported when moving a data-referenced alignment to a different site.
An issue has been resolved where a blank meny woould appear when right-clicking on a data-referenced object that had its source drawing renamed.
When using the Export to Civil 3D Drawing command, alignments are now exported as polylines as they have been in previous releases of AutoCAD Civil 3D.
An issue that prevented use of the command line to input a station range when using the Export Corridor to Solids command has been resolved.
An unexpected error is no longer generated when erasing an intersection while the Intersection Offset Parameter dialog box is open.
Export to DWG/DGN
An issue that prevented a successful drawing export to Microstation® DGN format has been resolved.
An error is no longer generated when exporting from a drawing that has been saved at the root directory of the local disk.
An issue has been resolved where the file browse dialog box for selecting a DWS file when exporting to DGN was not displayed.
An issue has been resolved where grading criteria sets were duplicated when attaching a referenced template.
An unexpected error is no longer generated when erasing a profile while the Profile Layout Tools toolbar is open.
An issue that prevented the Miscellaneous Utilities in the Toolbox from being run at the command line has been resolved.
Grading and Feature Lines
In AutoCAD Civil 3D 2017 Service Pack 1.1, running the AUDIT command after moving an overlapping feature line in a site no longer causes errors to be reported.
An issue that caused a grading object to not respond to changes in a feature line after a drawing audit has been resolved.
An issue has been resolved that caused the inlet grade dimensions to not match between the Hydraflow Storm Sewers extension and the Hydraflow Express extension.
When plotting an Inlet Section Table the “Inlet Depth” and “Inlet Spread” column headers have been changed to “Bypass Depth” and “Bypass Spread”.
An issue has been resolved that caused an error when applying changes after adding an empty column to a custom report in MyReport.
The Hydraflow Storm Sewers extension and the Hydraflow Express extension have updated calculations for gutter spread depth of curb inlets in sag.
The Hydraflow Storm Sewers Help has been updated so that definitions are consistent with the current behavior.
The Bypass Spread depth values in the Hydraflow Express extension now use the same rounding as in Hydraflow Storm Sewers extension.
The Hydraflow Storm Sewers extension and the Hydraflow Express extension in AutoCAD Civil 3D 2017 Service Pack 1.1 have updated calculations for gutter spread depth of curb inlets in sag.
Hydrology and Hydraulics
Linetypes that include blocks and text now are displayed correctly in AutoCAD Civil 3D 2017 Service Pack 1.1 when used for catchment boundaries or flow paths.
A feature has been added where a glyph and tooltip are shown when a label component has had its contents and/or format overridden.
An issue has been resolved where the default projection label style that was specified in the ProjectObjectsToMultiSect command settings was not retained when the Project Objects to Multiple Section Views command was run.
Pipe Networks and Pressure Networks
An issue that caused unexpected behavior when using grips to edit pressure network pipes in profile view has been resolved.
An issue has been resolved where some changes in a pressure network data shortcut were not synchronized to the referenced drawing.
An issue has been resolved where edits to the elevation of a pressure network were not retained when the pressure network was data-referenced.
An issue in AutoCAD Civil 3D 2017 Service Pack 1.1 has been resolved where pipe network styles were overwritten when synchronized in paper space.
